Machine torches
S1.1 Type (250mm) and Type S1.2 (110mm) Machine (ø 32 mm) Cuting Torch, intended for cutting machines and semi-automatic cuting devices, for 3-300 mm thick steel sheets by use of acetylene, propane-butane or natural gas. S1.3 Torch ref. No. 1021, intended for semi automatic devices, for cuting of 3 – 120 mm thick stell sheets by use of acetylene, propane-butane or natural gas.
1001; 1002
Torch – S 1.1
Acetylene – 1001
Propane-Butane and natural gas –1002
1021
Torch – S 1.3
2460
Torch – L250mm ZVEZDA
with nozzle for flat fit
Connectors Measures: GAS- R 3/8″LH; O2- R1/4″; O2- R3/8″
Manufactured and tested in complience with : JUS K.M6.020 JUS EN 730 2002
Machine torch nozzles
2452
Nozzle for flat fit – PB/Natural Gas
Nozzles are compatible with torch 2460
Nozzles 2452 For Manual Torch 2450 and 2451
| Cutting thickness mm | Nozzle tag | Oxygen pressure bar | Pressure PB/ZG bar |
| 1-10 | 2452/0 | 1.5-2 | 0.2 |
| 10-25 | 2452/1 | 2.5-3 | 0.2 |
| 25-50 | 2452/2 | 3-4 | 0.2 |
| 40-80 | 2452/3 | 3-4.5 | 0.2 |
| 80-150 | 2452/4 | 3.5-5.5 | 0.2 |
| 150-200 | 2452/5 | 4.5-5.5 | 0.2 |
| 200-300 | 2452/6 | 5-6 | 0.2 |
NOZZLE FOR TORCH CODE 1001 AC AND 1002 PB
M21x1.5
M8
M21x1.5
M8
| – | Metal sheet thickness (mm) | Nozle Ref. No. | |
| Acetylene | Propane-Butane | ||
| Iner | 3-10 | 1101 | 1111 |
| 10-25 | 1102 | 1112 | |
| 25-40 | 1003 | 1113 | |
| 40-60 | 1104 | 1114 | |
| 60-100 | 1105 | 1115 | |
| 100-200 | 1106 | 1116 | |
| 200-300 | 1107 | 1117 | |
| Outer | 3-100 | 1120 | 1118 |
| 100-300 | 1121 | 1119 | |
1003
MACHINE TORCH S1 ADAPTER S1, two cuts
